Lab Kits: ECE 385
Kit Variations
Selection based on previous enrollment, you will not need to select the variation at time of order.
Component Kit checked out by ECE 385 lab staff.
Urbana Boards must be returned at the end of the semester.
| ECE 385 A Kit | ECE 385 C Kit | ECE 385 D Kit |
|
|
|
Component Kit Contents
| Component Line Item | Manufacturer PN | Distributor PN | Part Description | Quantity |
| 1 | PTS645SL43-2 LFS | CKN9098-ND | Mini Pushbutton Switch | 3 |
| 2 | CF14JT330R | CF14JT330RTR-ND | 330Ω | 10 |
| 3 | CF14JT1K00 | CF14JT1K00TR-ND | 1kΩ | 10 |
| 4 | CF14JT10K0 | BC2665TB-ND | 100nf | 10 |
| 5 | CD74AC00E | 296-4214-5-ND | Quad NAND | 4 |
| 6 | CD74AC02E | 296-32940-5-ND | Quad NOR | 4 |
| 7 | CD74AC04E | 296-4217-5-ND | Hex Inverter | 4 |
| 8 | SN74HC10 | 296-8214-5-ND | Triple 3-input NAND | 4 |
| 9 | CD74AC20E | 296-4237-5-ND | Dual 4-input NAND | 4 |
| 10 | SN74HC27N | 296-12896-5-ND | Triple 3-input NOR | 4 |
| 11 | SN74HC74N | 296-1602-5-ND | Dual D-Type FF | 4 |
| 12 | CD74HC85E | 296-12821-5-ND | 4-bit Comp | 2 |
| 13 | SN74HC86N | 296-8375-5-ND | Quad XOR | 4 |
| 14 | CD74HC194E | 296-9183-5-ND | 4-bit BIDIR Shift Reg | 4 |
| 15 | CD74HC195E | 296-33045-5-ND | 4-bit Shift Reg w/ Parallel | 4 |
| 16 | CD74HCT163E | 296-12833-5-ND | 4-bit Sync Counter | 2 |
| 17 | SN74HC161N | 296-8244-5-ND | 4-bit binary counter | 2 |
| 18 | SN74HC109N | 296-8212-5-ND | Dual J/K | 4 |
| 19 | SN74HC151N | 296-8236-5-ND | 8:1 MUX | 4 |
| 20 | SN74HC153N | 296-8238-5-ND | Dual 4:1 MUX | 4 |
| 21 | SN74HC157N | 296-1578-5-ND | Quad 2:1 MUX | 4 |
| 22 | MV57164 | 1080-1184-ND | Multisegment LED | 4 |
| 23 | 76SB08T | GH7177-ND | 8 - DIP Switches | 2 |
| 24 | 76SC04T | 706-76SC04T | SPDT Raised Rocker 4 Pos | 1 |
